STANDARD EQUIPMENT
• All Rails Welded 316-L Stainless Steel
• All Hardware 316-L Stainless Steel
• Vinylester barrier coat over entire hull and hull sides

DECK/COCKPIT
• 10″ Stainless steel cleats; bow (2), stern with hawse pipes
(2 per side), spring line (2), bow (1)
• 10″ stainless steel pull-up cleats; cross tie cleats at
transom (2)
• Boarding ladder – covered telescoping swim ladder with
stainless steel grab rail
• Boarding Door – molded fiberglass boarding/dive door,
starboard side with removable telescoping stainless-steel
dive ladder with dedicated storage in dive door and flip out
re-boarding grab rail
• Bow eye – heavy duty polished stainless steel
• Coaming bolsters with integrated rope lights – cockpit
• Dockside cable TV inlet with low profile digital antenna on
hardtop and boost control in cabin
• Downrigger weight holders (2 port side)
• Freshwater shower with hot and cold water near dive door
and transom door.
• Freshwater washdown – stainless steel faucet located in
anchor locker
• Hawse pipe with integrated drink holders (1) port side
• Lighting – LED RGB diffused courtesy lighting dimmable
via app or GUI
• Lighting – digitally controlled blue Walkway lights with
automatic day/night senor (6)
• Livewell – pressurized insulated (19-gallon) in aft port corner
with clear lid, blue interior and dual red LED lights
• Logo – Chrome Boston Whaler Logo & model designator
• Rails – cockpit toe rail, stainless steel under gunnel storage
shelf with downrigger weight holders (Port side)
• Rails – hand rails; companion way to helm deck and into
cabin, boarding ladders, prep station – welded
stainless steel
• Rails – high bow rails, welded stainless steel
• Raw-water washdown – stainless steel faucet located
in cockpit
• Rod holders – forward deck mounted stainless steel (2)
• Rod holders – gunnel mounted stainless steel (5) – cockpit
foldout bench seat port side option deletes (1) rod holder
• Rod holders – transom mounted stainless steel (4)
• Rub rail – heavy duty white rub rail with stainless steel insert
• Self-bailing cockpit sole
• Transom door – 1.5″ thick acrylic with stainless steel latch
• Windlass with 400′ rode and chain with handheld remote
control, stainless steel swivel, polished stainless-steel anchor
(35 lbs) and polished stainless-steel bow roller davit

HELM CONSOLE – STARBOARD SIDE
• 16,000 BTU AC unit with 2 helm vents, wet bar area vent,
and discharge from hardtop to port helm deck
• Accent gelcoat color to reduce glare
• Compass with lighting
• Defogger system, port and starboard 120V heater
with blower
• Drink holders – Stainless steel; extended depth (1), standard
depth (1)
• Electrical switch panel with SS push button switches with
illuminated text
• Electronics mounting surface with space for dual 16″ or dual
19″ Simrad displays
• Footrest molded into console with solid teak steps with
satin finish
• Mercury DTS dual binnacle controls with integrated Auto
Drive Trim, push button start/stop controls
• Storage recess on top of dash with (1) dual USB
• Ignition key switches – located in the cabin MDP with push
button start/stop at helm
• Storage at starboard coaming pocket with (1) 12-V wireless
cell phone charging holder and LED light – blue
• Steering wheel – cast stainless steel with knob and tilt helm
• Stereo volume control – JL Audio®
• Trim tab control

16″ SIMRAD NSO EVO3S ELECTRONICS /
DUAL NAVIGATION PACKAGE
• Dash surface – custom black acrylic integrated with switch
panels and flush mounting of dual displays
• Simrad NSO evo3S 16″ screen (GPS, Chart Plotter, Fishfinder)
• Simrad NSO evo3S 16″ screen (Additional Display)
• Active Imaging 3 in 1 Transom Mount Transducer (CHIRP,
SideScan, DownScan)
• Integrated Mercury VesselView® Link
• Simrad RS40 VHF Radio with AIS and HS40 wireless
handset ‘

STARBOARD HELM DECK WET BAR
• Countertop – solid surface
• Drink holders – Stainless steel; extended depth (1),
standard depth (1)
• Rail – stainless steel handrail
• Receptacle 120-V
• Refrigerator / freezer – stainless steel 12-V / 120-V, 3.0 cuft.
• Sink with SS faucet (hot and cold), with filler cutting board
and dedicated filler cutting board storage
• Wood accents – Teak wood facia under the counter edge

STARBOARD COCKPIT PREP &
ENTERTAINMENT CENTER
• Prep area with solid surface counter and pull-out
electric grill
• Pull-out drawer storage compartment on starboard cockpit
wall includes 5-gallon pail and grill utensil storage

PORT COCKPIT STORAGE CENTER
• Drawers (2)
• Footrest – pull-out for port aft facing convertible seat

PORT LOUNGE AND CONSOLE
• Acrylic/glass dash
• Storage recess on top of dash
• Storage: glovebox style with (1) USB-A / USB-C and LED
light – blue

SEATING
• Port aft seat – forward facing; 2-person seat with conversion
seatback for aft facing mezzanine seat
• Pullout footrest at portside conversion seatback for aft
facing seat
• Port Console seat – Single person seat with conversion
seatback to face forward or face aft for dinette seating.
• Table – Teak, satin finish with electric high/low pedestal
converting from dinette to lounge in low position
• Lounge filler cushions
• Helm seat – fore and aft electrically adjusted with swivel
• Cockpit foldout stern bench seat

STORAGE
• Bilge storage box – dedicated open storage
• Bow anchor locker with drains with LED light
• Cabinets – Interior: Teak Straight Grain finish
• Cabin – cabinets at galley
• Cabin – cedar lined hanging locker with light and
• cubby storage
• Cabin – mid berth port side storage compartment
• Cabin – under port settee seating
• Helm deck – storage in port seat
• Helm deck – storage under port electric table with LED
light – white
• Cockpit – downrigger weight holders (2)
• Cockpit – storage with 5-gallon pail and grill utensil storage
• Cockpit – rod holders under gunnel port (2) (deleted
with port foldout bench seat option)
• Cockpit wet bar – includes hot/cold faucet with stowable
dual purpose cutting board/work surface sink cover
• Fishboxes – 50 gallon capacity (ea), insulated in deck with
pump-out (2)

OPEN WINDSHIELD HARDTOP SYSTEM
• Canvas – side and aft rigid Makrolon® polycarbonate
weather enclosure with door to cockpit, black Stamoid®
• Deck hatch – manual opening, integrated into hardtop
• Horn – electric dual polished stainless-steel trumpet horns
• Integrated aluminum hardtop/windshield frame – black
• Ladder access to hardtop (white or black depending on
frame color selection)
• LED flood lights – cockpit (2), bow (1)
• LED navigation lights, stainless steel, recessed in hardtop
• LED RGBW map/overhead lights
• Open tempered side glass
• Outrigger ready
• Rail – Handhold along hardtop for egress to foredeck
• Rod holders (4)
• Speakers – Premium integrated JL Audio 7.7″ speakers
(aft)(2)
• Windshield – full height, single piece front tempered glass
providing unobstructed visibility, with dual electric
• actuated vents with independent control
• Windshield wipers – (2) pantograph, with intermittent
control and wash system

CABIN INTERIOR
• 32″ flat screen HDTV with remote HDMI connection
• Carbon monoxide and smoke detectors
• LED overhead lights (10)
• LED RGB diffused courtesy lighting dimmable via app
or GUI
• Easy to clean interior materials
• Hardwood cabin sole – teak
• Lockable acrylic cabin door
• Skylights
• Microwave

FORWARD BERTH
• 120-V receptacle (Port and Starboard side)
• USB power receptacle (Port and Starboard side)
• Drink holders – Stainless steel standard depth (4)
• Opening hatch with solar shade and sky screen
• Overhead Reading lights (2)
• LED RGB overhead and floor accent lighting dimmable via
app or GUI
• V-berth dinette with high gloss wood table. Table drops
with electrically actuated pedestal enabling V-berth seating
to convert into queen size island bed with fitted sheet,
comforter, and two regular size pillowcases

MID BERTH
• Hardwood cabin sole – teak
• Privacy curtain
• Overhead Reading lights (3)
• Headboard flip down storage (port)
• U-shape seating that converts to berth
• 120V receptacle
• USB power receptacle

PORT SETTEE
• Large 3 person settee
• Convertible settee seat back for prep/work surface
• Overhead under cabinet LED light – white
• Under seat insulated storage

STEREO/INFOTAINMENT SYSTEMS
• Premium DSP tuned multi Zone System with
hideway receiver (JL Audio integration into
Simrad Navigation Package)
• JL Audio MM105-HR stereo with Dash mounted stereo
remote volume/mute knob
• AM/FM/HD Radio, dual USB and dual AUX input
• iPod / iPhone / Android compatible via integrated Bluetooth
5.0 or USB (lossless compatible)
• Sirius XM option ready
• JL Audio Digital Signal Processor (DSP) system with custom
tuned audio, optimized for audiophile experience.
• Helm Deck
• JL stereo speakers M6 7.7″ coax classic white/Gun metal grill
(2) on port and starboard consoles
• reflecting off the windshield
• JL stereo speakers M6 7.7″ coax classic white/Gun metal grill
(2) in aft part of hardtop
• Stereo remote control – JL Audio Wireless remote at helm
and in lounge area that controls the stereo
• and volume of the 4 speakers Cockpit
• JL 7.7″ coax classic white/Gun metal grill (2) in aft corners
• Cabin Main Area
• TV, 32″ flat screen LED HDTV with remote HDMI connection
adjacent to 120V outlet
• JL 6.5″ coax interior speakers
• Stereo remote control

HEAD
• 500 GPH shower sump
• Flooring – solid surface flooring in the shower and solid teak
flooring on the vanity area
• LED overhead lighting
• LED RGB diffused courtesy lighting
• Powered ventilation
• Enclosed shower; rain shower head with hand-held sprayer
with hot and cold faucet, and Bi-fold acrylic shower divider
• Split head arrangement includes clear acrylic partition for
a dry head
• Sink
• Sky light
• Soap holder
• Solid surface vanity countertop
• Toilet paper holder
• Towel bar and ring
• Vacu-Flush® toilet, holding tank with vent filter, overboard
discharge, dockside pump-out, tank full indicator alert and
progressive tank level indication integrated into digital
network
• Vanity grab rail
• Vanity storage
• 120-V receptacle

MECHANICAL
• 400 V10 DTS Triple Mercury Black Verado FourStrokes with
Joystick Piloting. Outboard docking system with joystick
electronic steering and electronic remote control (ERC)
(91 octane fuel recommended)
• Tilt steering
• 410 gallon aluminum fuel tank
• Advanced battery management system; electric switches
with pushbutton paralleling
• Air conditioner (cabin) (16,000 BTU), reverse cycle
• Air conditioning (cockpit) (16,000 BTU), reverse cycle
• Battery charger – 40 AMP @ 12-V multistage
charger (engine)
• Battery charger – 40 AMP @ 12-V multistage charger
(house)
• Battery trays with remote switches and automatic
charging/paralleling relays
• Bilge pump – high water bilge pump with alarm (2000 GPH)
• Bilge pumps – automatic (800 GHP fwd, 2000 GPH aft)
• Bonding system for underwater through hull fittings
• Engine and fuel/water separators
• Freshwater hot and cold-water system with dockside hook
up and tank level indicator – 52-gallon tank,
• Generator (Diesel 12kW Fischer Panda) 240-V 60 Hz with fire
suppression system, automatic with manual override
• Machinery space lighting
• Manifold plumbing system with individual valve per circuit
• Propellers – stainless steel
• Electric trim tabs with indicator
• Shore power inlets single 240V – 50-amp with isolation
transformers
• Thru hulls – cast bronze thru hulls (below waterline)
• Thru hulls – cast stainless steel thru hulls (above waterline)
• Transducer pocket in hull bottom for flush mounting a B275
transducer
• Windlass with 400′ rode and chain with handheld remote
control, stainless steel swivel, polished stainless-steel anchor
(35 lbs) and polished stainless-steel bow roller davit
